Perma-Cal 101FTM09B21 - 600psi - Pressure Gauge - IN STOCK
ONE MOVING PART
Unmatched vibration, pulsation and shock performance. No linkages, springs, gears, or liquid fill to wear, break or leak.
TRAVEL READY
Survives the day to day beatings of an industrial environment or a bumpy ride in the back of a pickup.
TRUSTED ACCURACY
Accuracy is 25% less affected by temp fluctuations. Trusted in extremes from -65°F up to 600°F media. Inconel Element = Low Coefficient of Thermal Expansion
AEROSPACE QUALITY | MILITARY TRUSTED
Direct Drive is demanded on critical applications. The same military grade Direct Drive technology used in our Aerospace and Military designs is used in our industrial gauges for commercial applications.
SEE SPECS BELOW
PERMA-CAL 101FTM09B21
TYPE: Pressure Gauge
ACCURACY: ±0.25% F.S. (Calibration Certificate included)
DIAL SIZE: 4.5"
CASE TYPE: Front Flange (2.5”, 4.5”, 6”, 8.5”)
POINTER TYPE: Test (knife-edged, precision reading)
DIAL TRIM SPECS: 2.5", 4.5", 6", 8.5"; Mirror Band, Pointer Dampening, External Zero Adjust, Stainless Steel
PRESSURE RANGE: 600psi
COLOR: BLUE
FITTING POSITION: Bottom (6 o’clock)
STANDARD CONNECTION: 1/4 NPT
