TESCOM 26-2500 Series has a Cv = 5.0 for high flow backpressure applications. Large diaphragm provides excellent sensitivity and minimal crack-to-reseat pressure differential.
• Pump discharge pressure control
• High flow capacity.
• Close pressure differential between crack & reseat.
• Bubble-tight shutoff at all reseating pressures.
• Large diaphragm provides maximum sensitivity.
• Dome-loaded and air-actuated options are available.
• Four control pressure ranges.
NEVER USED
**** STOCKED ITEM LISTED AT DISCOUNTED PRICE.****
Contact us direct for other options on customizable Tescom regulators.
TESCOM 26-2500 Series has a Cv = 5.0 for high flow backpressure applications. Large diaphragm provides excellent sensitivity and minimal crack-to-reseat pressure differential.
• Pump discharge pressure control
• High flow capacity.
• Close pressure differential between crack & reseat.
• Bubble-tight shutoff at all reseating pressures.
• Large diaphragm provides maximum sensitivity.
• Dome-loaded and air-actuated options are available.
• Four control pressure ranges.
NEVER USED
**** STOCKED ITEM LISTED AT DISCOUNTED PRICE.****
Contact us direct for other options on customizable Tescom regulators.
SERIES: 26-25
BODY, BONNET, BACK-CAP MTL: Brass
INLET PRESSURE: 0-200 psig, 0-13.8 bar
O-RING & VALVE SEAT MTL: Nitrile, Buna-N 90 Durometer
INLET AND OUTLET PORT TYPE: NPTF
INLET AND OUTLET PORT SIZE: 1/2"
LOAD: Spring load, handknob adjust
DIAPHRAGM MATERIAL: PTFE
PORTING CONFIGURATION: 2 gauge ports at 60°
